2017-01-11
Sitong oil gas fired boiler is high efficiency (as high as 98%), energy saving and environmental protection. The fuel could be heavy oil, diesel, city gas, natural gas, LPG, etc. The main types includes WNS series oil gas fire tube boiler, SZS series oil gas water tube boiler, and vertical type once through structure oil gas fired boiler.
Fuel Consumption of WNS Series Oil Gas Fire Tube Steam Boiler
|
Rated Evaporation Capacity (t/h) |
1 |
2 |
4 |
6 |
8 |
15 |
20 |
|
Light oil (kg/h) |
66.5 |
133 |
266 |
399 |
532 |
997 |
1204 |
|
Natural gas (Nm3/h) |
75 |
150 |
300 |
450 |
600 |
1125 |
1418 |
|
Note: parameter is just for reference, please inquire for the specific details. |
|||||||
Fuel Consumption of WNS Series Oil Gas Fire Tube Hot Water Boiler
|
Rated Power (MW) |
1.05 |
1.75 |
2.1 |
4.2 |
7 |
|
Light oil (kg/h) |
98.5 |
164.2 |
197 |
394 |
656.7 |
|
Liquefied Natural gas (Nm3/h) |
119.4 |
198.9 |
238.7 |
477.5 |
795.8 |
|
City Gas (Nm3/h) |
253.7 |
422.8 |
507.3 |
1014.6 |
1691 |
|
Note: parameter is just for reference, please inquire for the specific details. |
|||||
Fuel Consumption of Vertical Type Once Through Structure Oil Gas Fired Boiler
|
Rated Evaporation Capacity (kg/h) |
200 |
300 |
500 |
600 |
1000 |
2000 |
|
13 A (Nm3/h) |
12.4 |
18 |
30 |
36 |
85~90 |
113~121 |
|
LPG Propane (kg/h) |
10.7 |
15.5 |
26 |
31 |
73~78 |
98~105 |
|
LPG Butane (kg/h) |
11.3 |
16.5 |
27 |
33 |
77~82 |
103~110 |
|
Note: parameter is just for reference, please inquire for the specific details. |
||||||
Sitong Boiler Co., Ltd is the professional manufacturer of Grade A industrial boilers, engages in industrial boiler design, manufacturing, transportation, installation, and after-sale service.
